At a glance
Apple M4 chipProcessor
General
Introduction2024
Apple IntelligenceCompatible
Finish
FinishSilver
Chip
Apple M4 chip10‑core CPU with 4 performance cores and 6 efficiency cores
10-core GPU
Hardware-accelerated ray tracing
16‑core Neural Engine
120 GB/s memory bandwidth
Media engineHardware-accelerated H.264, HEVC, ProRes and ProRes RAW
Video decoding engine
Video encoding engine
ProRes encoding and decoding engine
AV1 decode
Apple M4 Pro chip12-core CPU with 8 performance cores and 4 efficiency cores
16-core GPU
Hardware-accelerated ray tracing
16‑core Neural Engine
273 GB/s memory bandwidth
Media engineHardware-accelerated H.264, HEVC, ProRes and ProRes RAW
Video decoding engine
Video encoding engine
ProRes encoding and decoding engine
AV1 decode
Configurable with:
M4 Pro with 14-core CPU and 20-core GPU
Memory
Apple M4 chip16 GB unified memory, Configurable with:, 24 GB or 32 GB
Apple M4 Pro chip24 GB unified memory, Configurable with:, 48 GB or 64 GB
Storage
Apple M4 chip256 GB SSD, Configurable with:, 512 GB, 1 TB or 2 TB
Apple M4 Pro chip512 GB SSD, Configurable with:, 1 TB, 2 TB, 4 TB or 8 TB
Display support
Up to three displaystwo displays with a resolution up to 6K at 60 Hz over Thunderbolt and one display with a resolution up to 5K at 60 Hz over Thunderbolt or a 4K resolution at 60 Hz over HDMI
Up to two displaysone display with a resolution up to 5K at 60 Hz over Thunderbolt and one display with a resolution up to 8K at 60 Hz or a 4K resolution at 240 Hz over Thunderbolt or HDMI
Digital video output via Thunderbolt 4Native DisplayPort 1.4 output over USB-C
Up to three displaysthree displays with a resolution up to 6K at 60 Hz over Thunderbolt or HDMI
Up to two displaysone display with a resolution up to 6K at 60 Hz over Thunderbolt and one display with a resolution up to 8K at 60 Hz or a resolution up to 4K at 240 Hz over Thunderbolt or HDMI
Digital video output via Thunderbolt 5Native DisplayPort 2.1 output over USB-C
HDMI display outputSupport for one display with a resolution up to 8K at 60 Hz or a resolution up to 4K at 240 Hz (M4 and M4 Pro)
Video playback
Video playbackSupported formats include HEVC, H.264, AV1 and ProRes
HDR with Dolby Vision, HDR10+/HDR10 and HLG
Audio playback
Audio playbackSupported formats include AAC, MP3, Apple Lossless, FLAC, Dolby Digital, Dolby Digital Plus and Dolby Atmos
Audio
AudioBuilt-in speaker
Mini‑jack connector with advanced support for high‑impedance headphones
HDMI port supports multichannel audio output
Connections and expansion
Connections and expansionFront:Two USB-C ports with support for USB 3 (up to 10 Gb/s)
Mini‑jack connector
Back (M4):Gigabit Ethernet port (configurable with 10-Gb Ethernet)
HDMI port
Three Thunderbolt 4 ports (USB-C) with support for:Thunderbolt 4 (up to 40 Gb/s)
USB 4 (up to 40 Gb/s)
DisplayPort
Back (M4 Pro):Gigabit Ethernet port (configurable with 10-Gb Ethernet)
HDMI port
Three Thunderbolt 5 ports (USB-C) with support for:Thunderbolt 5 (up to 120 Gb/s)
USB 4 (up to 120 Gb/s)
DisplayPort
Communication
Wi-FiWi-Fi 6E (802.11ax)
BluetoothBluetooth 5.3
Ethernet10/100/1000BASE-T Gigabit Ethernet (RJ-45 connector)
Configurable with 10-Gb Ethernet (Nbase-T Ethernet with support for 1-Gb, 2.5-Gb, 5-Gb and 10-Gb Ethernet via RJ-45 connector)
Dimensions and weight
Height5.0 cm
Width12.7 cm
Depth12.7 cm
Weight (M4)0.67 kg
Weight (M4 Pro)0.73 kg
Power supply and environment
Line voltage100-240 V AC
Frequency50-60 Hz, single phase
Maximum continuous power155 W
Operating temperature10 to 35 °C
Storage temperature-40 to 47 °C
Relative humidity5-90%, non-condensing
Operating altitudetested up to 5000 m
Standard acoustic performanceSound pressure level (operator position): 5 dBA (when idle)
